Single Phase Dry Type Transformer – High‑Efficiency OEM/ODM Supplier for USA

You need a reliable, low‑maintenance transformer that meets strict US safety standards while keeping total cost of ownership low. Our single phase dry type transformer delivers 35 % lower energy loss, CE/FCC/UL certifications, and rapid 2‑week delivery for OEM and ODM projects.

Get Free Quote in 24 h

Why Your Current Transformer Is Holding Back Production

Corporate purchasing managers in the USA report three recurring pain points:

High upfront price – Conventional oil‑filled units cost up to 25 % more than dry‑type alternatives.
Frequent downtime – Over‑heating and oil leaks cause unplanned shutdowns, averaging 4 hours per incident.
Regulatory risk – Non‑compliant designs lead to costly re‑certifications and shipment delays.

According to a 2025 IEC survey, 62 % of US manufacturers plan to replace oil‑filled transformers within the next 3 years to meet sustainability goals.

See how our solution eliminates these risks →

Our Single Phase Dry Type Transformer – The Complete Solution

Core Advantages

Energy‑Efficient Core – Up to 37 % lower no‑load loss (EN 60214‑3).
Compact, Lightweight Design – 30 % lighter than oil‑filled equivalents, reducing installation labor.
Zero‑Leak, Low‑Noise Operation – Ideal for indoor facilities and hospitals.
Full Certification Suite – CE, UL, FCC, RoHS, ISO 9001, VDE, CB, GS.
OEM/ODM Flexibility – Custom winding, enclosure, and voltage ratings from 120 V to 600 V.
Fast‑Track Delivery – 10‑day standard production, 5‑day rush for stocked cores.

Technical Specifications

Parameter	Standard Range	Typical Value
Rated Power	0.5 kVA – 500 kVA	150 kVA
Frequency	50/60 Hz	60 Hz
Insulation Class	Class B / F	Class F
Temperature Rise	≤ 55 °C	45 °C
Noise Level	≤ 55 dB(A)	48 dB(A)
Dimensions (H×W×D)	Custom	800×600×400 mm
Weight	30 kg – 2 t	420 kg

Application Scenarios & Case Studies

Industrial Automation Plant – USA

Challenge: Existing oil‑filled units caused 12 % annual energy loss.
Solution: Replaced 20 units with our 150 kVA dry‑type models.
Result: 34 % reduction in operating cost, zero leakage incidents, ROI achieved in 9 months.

Medical Imaging Facility – California

Challenge: Strict IEC‑60601‑1 noise limits.
Solution: Customized low‑noise enclosure with sound‑absorbing panels.
Result: Noise dropped from 62 dB to 45 dB, compliance passed on first audit.

Start your own case study – request a free design review →

Frequently Asked Questions

What is the typical lead time for a custom single phase dry type transformer?

Standard stock units ship within 10 days. Custom OEM designs (winding, enclosure, voltage) are usually delivered in 3‑4 weeks after final engineering approval.

Can you provide CE, UL, and FCC certifications for the US market?

Yes. Every unit is tested and stamped with CE, UL 1449, FCC Part 15, and RoHS compliance. Test reports are available on request.

Do you offer sample units before full production?

We provide a 5‑unit engineering sample at 30 % of the total order value, fully refundable if you decide not to proceed.

Low Power Transformer

What are the payment terms for large OEM orders?

Standard terms are 30 % T/T upfront, 70 % upon shipment. For trusted partners we accept L/C at sight or net‑30 days after delivery.

How do you handle after‑sales service and warranty?

All transformers carry a 24‑month warranty covering material and workmanship. Our technical support team is available 24 h/7 d via email, WhatsApp, or phone.

Have more questions? Get a live demo now →

Ready to Upgrade Your Power Infrastructure?

Limited‑time offer: **Free engineering sample** for orders placed before May 31 2026. No‑risk, money‑back guarantee if the unit does not meet your specifications.

Email Quote Now WhatsApp Chat

Call us: +86 131 2826 415 | +86 0752‑3388753

What Our Clients Say

Mark T., Purchasing Manager, SolarTech USA
“The price was 18 % lower than our previous supplier, and the transformer’s quiet operation helped us meet our LEED certification.”

Emily R., CTO, GreenEnergy Solutions
“Xinchangda’s rapid prototyping cut our time‑to‑market by 40 %. The unit passed all US safety tests on first try.”

David L., Facility Engineer, Midwest Foods
“Since installing the dry‑type transformer, we have seen a 30 % reduction in maintenance cost and zero oil‑spill incidents.”
