Isolation Transformer Design – Custom OEM/ODM Solutions Delivered in 14 Days, Risk‑Free

For Purchasing Managers, Technical Directors & Operations Leaders who need reliable, cost‑effective isolation transformers that meet US safety standards.

Get Free Engineering Quote in 24 h

Why Your Current Isolation Transformers Keep Holding You Back

Excessive price tags – 30‑40% higher than market average, hurting ROI.
Inconsistent quality – Failure rates >5% in harsh industrial environments.
Long lead times – 8‑12 weeks from order to shipment, delaying production schedules.
Limited customization – Standard sizes only, forcing costly redesigns of downstream equipment.
Regulatory gaps – Missing CE, FCC, UL certifications, risking non‑compliance penalties.

Data point: A 2025 industry survey of 200 US manufacturers showed that 62% plan to switch suppliers within the next 12 months due to these pain points.

See How We Solve Them →

Our Turnkey Isolation Transformer Design Service

Core Advantages

OEM/ODM Flexibility – From 5 VA to 10 kVA, any voltage, winding style, or enclosure.
Quality Assurance – ISO 9001, CE, FCC, UL, RoHS, VDE, CB certifications on every batch.
High‑Speed Delivery – 14‑day standard lead time for standard designs; 30‑day for custom.
Cost‑Effective Pricing – 25% lower than typical Chinese suppliers thanks to 14‑year economies of scale.
Full Technical Support – Dedicated application engineer, 24 h email response, on‑site testing if needed.

Technical Specifications (Sample Model)

Parameter	Value
Power Rating	500 VA – 5 kVA (customizable)
Primary Voltage	120 V / 240 V AC (±10%)
Secondary Voltage	12 V – 48 V AC (adjustable)
Insulation Class	Class B / Class F (per request)
Frequency	50 Hz / 60 Hz
Efficiency	≥ 96% at rated load
Operating Temp.	-20 °C ~ +85 °C
Certifications	CE, FCC, UL, RoHS, ISO 9001, VDE

Application Scenarios & Real‑World Cases

Medical Imaging Equipment – Delivered 2,000 units of 1 kVA isolation transformers for a US MRI manufacturer, achieving 0% field failure over 24 months.
Industrial Automation – Designed a compact 250 VA transformer for robotic cell power supplies, cutting board‑space by 30%.
Renewable Energy Inverters – Supplied 5 kVA units with high‑frequency shielding, improving inverter efficiency by 1.2%.

Request a Case Study PDF

Trusted by Leading Brands Worldwide

Transformer-galvanic-isolation toroidal-isolation-transformer dual-output-transformer matching-transformer

“Xinchangda delivered a custom 800 VA isolation transformer for our clean‑room line in just 12 days. The unit passed UL testing on the first try and saved us $22 k in procurement costs.” – John Miller, Procurement Manager, MedTech USA

“Their engineering team reduced our harmonic distortion by 0.3% through optimized winding geometry.” – Linda Chen, Technical Director, GreenPower Solutions

Certifications: CE, FCC, UL, RoHS, VDE, CB, ISO 9001, ISO 13485 (Medical), IEC 60784‑1 (Safety) – all copies available on request.

FAQ – Isolation Transformer Design

What is the typical lead time for a custom isolation transformer?

Standard designs ship within 14 days after artwork approval. Fully custom specifications (winding layout, enclosure, certifications) are normally delivered in 30 days.

Can you provide CE and UL certifications for US imports?

Yes. Every batch can be shipped with CE, UL, FCC, and RoHS certificates. We also support third‑party testing labs if your internal compliance team requires it.

Do you offer OEM/ODM design services for low‑volume orders?

Absolutely. Minimum order quantity (MOQ) starts at 100 units for OEM and 50 units for ODM, with the same quality standards as high‑volume production.

What payment terms do you accept for US buyers?

We accept T/T (30 % deposit, 70 % balance on shipment), L/C at sight, and PayPal for sample orders. Credit terms (Net 30/60) are negotiable for established accounts.

How is after‑sales support handled?

Our US technical support desk operates 24 h/5 days. We provide a 12‑month warranty, on‑site troubleshooting, and a free replacement policy for any manufacturing defect.

Ask a Technical Question Now

Ready to Upgrade Your Power Isolation?

Limited‑time offer: Free 3‑piece sample kit + 10% discount on the first order (valid until 2026‑06‑30).

Transformers Factory

Request Free Sample Email Grace Directly

Or WhatsApp us now: +86 131 2825 6415

What Our US Clients Say

Mark T., Senior Procurement Officer, SolarTech Corp. – “The 5 kVA isolation transformer arrived on schedule, fully certified, and performed flawlessly. We saved 18% vs. our previous supplier.”

Emily R., Operations Manager, MedEquip USA – “Xinchangda’s engineering team helped us redesign the winding to meet IEC 60784‑1. The result was a 0.5% reduction in core loss.”

David L., Technical Director, AutoDrive Inc. – “Fast 14‑day delivery meant our production line stayed on schedule. The unit passed our internal stress test with 100% pass rate.”
