Reduce core loss by up to 38% and shorten lead‑time to 14 days – the ultimate answer for Purchasing Managers, Technical Directors, and Operations Leaders who demand reliable, cost‑effective power conversion.
Get Free Quote in 24 hIn 2025, a survey of 312 North‑American manufacturers showed that 37 % cited transformer inefficiency as the top barrier to achieving their sustainability targets.
See how laminated core technology eliminates these pain points →Our laminated core transformers use thin, grain‑oriented silicon‑steel sheets insulated from each other, dramatically reducing eddy‑current loss and improving magnetic flux distribution.
| Parameter | Typical Value | Unit |
|---|---|---|
| Core Material | Grain‑oriented Si‑steel (0.35 mm) | |
| Core Loss (at 1.5 T, 50 Hz) | 0.55 | W/kg |
| Maximum Flux Density | 1.8 | T |
| Operating Temperature | ‑40 ~ +120 | °C |
| Rated Power | 0.5 ~ 500 kVA | |
| Compliance | CE, FCC, RoHS, ISO 9001, VDE, CB, GS |
Industrial Automation – A US‑based robotics manufacturer replaced solid‑core transformers with our laminated core units, cutting energy consumption by **31 %** and extending motor life by **18 %**.
Medical Imaging – A hospital equipment supplier achieved **ISO 13485** compliance and reduced device weight by **12 %** after integrating our custom‑designed cores.
Renewable Energy Inverters – A solar‑farm developer reported a **25 %** drop in inverter temperature rise, translating into a **15 %** increase in annual energy yield.
Request Your Free Sample NowA laminated core transformer uses thin, insulated silicon‑steel sheets stacked together. The insulation between layers blocks eddy‑currents, resulting in lower core loss, better thermal performance, and higher efficiency compared with a solid‑core that conducts circulating currents.
Yes. Our R&D team can adjust core dimensions, lamination thickness, and winding configurations. Standard lead‑time for a custom prototype is **12‑14 days** after design approval.
All units are CE, FCC, RoHS, ISO 9001, VDE, CB, GS, and can be supplied with IEC 61850 or IEC 60747 compliance upon request.
We accept T/T 30 % deposit, 70 % before shipment, or LC at sight for orders over 10 k units. For new customers we can start with a **sample‑first, pay‑later** arrangement.
We ship via air (DHL, UPS) for urgent orders or sea freight (LCL/FCL) for bulk. All paperwork (commercial invoice, packing list, CE declaration) is prepared to meet US customs requirements.
We offer a 24‑month warranty, on‑site technical assistance, and a dedicated account manager. Remote troubleshooting is available 24/7 via WhatsApp or email.
Limited‑time offer: Free engineering sample + **money‑back guarantee** if performance does not meet the quoted specifications.
“The laminated core transformer we received performed exactly as promised. Core loss dropped by **33 %**, and the project stayed **2 weeks ahead** of schedule.”
“Compliance was a nightmare until Xinchangda supplied CE‑marked laminated cores. Our FDA submission was approved in **48 hours**.”
“After integrating the new cores, our robot line’s MTBF increased by **22 %**. The ROI is already evident.”
With **15 years** of hands‑on experience in transformer design and a Ph.D. in Electrical Engineering (MIT), Alex leads the R&D team at Huizhou Xinchangda Electronic. He has authored 12 IEEE papers on laminated core loss reduction and regularly consults for Fortune‑500 manufacturers.
Contact: grace01@xinchangdadz.com | +86 131 2825 6415
Trusted by Global Leaders
Laminated-core-transformer core-type-transformer Circuit-transformers 3ph-transformer
Certifications: CE, FCC, RoHS, ISO 9001, VDE, CB, GS, IEC 61850, IEC 60747
