Accelerate your power‑design cycles with high‑accuracy LTspice coupled inductor models that meet ISO‑9001 quality standards and ship within 2 weeks.
Get Free Quote in 24 h| Parameter | Typical Value | Tolerance | Package |
|---|---|---|---|
| Primary Inductance (L1) | 10 µH | ±3 % | SMD 1210 |
| Secondary Inductance (L2) | 5 µH | ±3 % | SMD 1210 |
| Coupling Coefficient (k) | 0.95 | ±0.02 | — |
| Current Rating | 2 A | — | — |
| Operating Temp. | ‑40 °C ~ +125 °C | — | — |
