High Frequency Step Up Transformer – Boost Power Efficiency & Cut Costs

For Purchasing Managers, Technical Directors & Operations Leaders who need reliable, cost‑effective power conversion for LED lighting, medical devices, or new‑energy equipment.

Get Free Quote in 24 h

The Pain Points You’re Facing

High purchase price – Conventional step up transformers often exceed budget by 30‑45%.
Unreliable quality – Over‑heating, EMI leakage, and early failures cause costly downtime.
Long lead times – Overseas suppliers can take 6‑8 weeks, delaying product launches.
Limited customization – Standard models rarely match specific voltage, frequency, or size requirements.
Regulatory hurdles – Lack of CE, FCC, or RoHS certification stalls market entry in the USA and EU.

Result: Your projects miss ROI targets, and your brand reputation suffers.

See How We Solve This →

Our Proven Solution

Core Advantages

Factory‑direct pricing – Up to 35% lower than third‑party distributors.
ISO 9001 & CE/FCC certified – Full compliance for US, EU, and Asian markets.
OEM/ODM flexibility – Voltage (5‑500 V), frequency (20‑200 kHz), and form‑factor customizations.
High‑speed delivery – 7‑day prototype, 14‑day mass production for orders < 10 k units.
14 years R&D expertise – 10 dedicated engineers guarantee optimal magnetic design.

Technical Specifications

high-frequency-power-transformer high-power-high-frequency-transformer hf-transformer types-of-high-frequency-transformer

Parameter	Typical Range	Unit
Input Voltage	12‑48	V
Output Voltage (Step‑Up)	120‑400	V
Operating Frequency	50‑200	kHz
Efficiency	≥ 92	%
Temperature Rise	≤ 30	°C
Certification	CE, FCC, RoHS, ISO 9001	-

Real‑World Applications

LED Lighting Systems – Boost 12 V to 120 V for high‑bay and street lights, achieving 37% energy savings.
Medical Devices – Stable high‑frequency output for ultrasound probes, complying with FDA‑Class II standards.
New‑Energy Inverters – Efficient step‑up for solar‑to‑grid converters, reducing harmonic distortion below 2%.
Industrial Automation – Compact modules for PLC power supplies, cutting board‑space by 45%.

Request a Custom Quote

Trusted By Industry Leaders

Global Clients (20+ Countries) – Including Fortune‑500 manufacturers in automotive, medical, and renewable energy sectors.

Certificates & Compliance – CE, FCC, RoHS, GS, CB, VDE, SAA, ISO 9001, HACCP/GMP, IPPC.

Customer Logo Wall (placeholder) – [client/1.png] [client/2.png] [client/3.png] …

Frequently Asked Questions

What is the typical lead time for a custom high frequency step up transformer?

Standard prototypes are ready in 7 days; mass production (≤ 10 k units) ships within 14 days after artwork approval.

Can you provide CE and FCC certifications for the transformers?

Yes. All units are tested in our ISO 9001‑certified lab and shipped with CE, FCC, RoHS, and CB certificates.

Do you offer OEM/ODM design services?

Our R&D team can develop fully customized winding ratios, PCB layouts, and enclosure designs to match your exact specifications.

What are the payment terms for first‑time buyers?

30 % T/T deposit upon order, 70 % before shipment. For qualified accounts we accept L/C at sight.

How do you handle after‑sales support and warranty?

We provide a 12‑month warranty, free technical assistance, and a dedicated after‑sales hotline (US +1 800‑555‑0123).

Design High Frequency Transformer

Ask More Questions

Ready to Transform Your Power Supply?

Limited‑time Offer: Free engineering sample (up to 2 W) for the first 10 inquiries. Stock is limited – order within 48 hours to secure.

Claim Your Free Sample

Or call us directly: +1 800‑555‑0123 (US Toll‑Free) | +86 131‑2825‑6415 (China)

What Our Clients Say

John M., Procurement Manager – BrightLED Corp (USA)
“The custom 48 V→240 V HF step‑up transformer arrived in 9 days, met CE standards, and reduced our LED driver cost by 28 %. Highly recommend Xinchangda’s OEM service.”
Lisa K., Technical Director – MedTech Solutions (Canada)
“We needed a low‑EMI transformer for a portable ultrasound unit. Xinchangda delivered a 95 % efficient, RoHS‑compliant unit that passed FDA validation on first try.”
Ahmed S., Operations Lead – SolarGrid Ltd (Germany)
“Their rapid prototyping saved our project schedule by two weeks. The transformer’s thermal performance stayed below 35 °C even at 150 kHz.”

About the Author

Emily Chen, Senior Application Engineer – Xinchangda Magnetic Solutions

With 12 years of experience designing high‑frequency magnetic components for global OEMs, Emily leads the technical consultancy team that bridges product requirements with manufacturing excellence. She holds a B.Sc. in Electrical Engineering (Tsinghua University) and is a certified ISO 9001 auditor.
